Pantum BP5200DN Mono laser single function printer

Product

BP5200DN

Control panel

2 line LCD

Processor speed

1.2G Hz

Memory

1GB

Hard disc

NO

Recommended Monthly Duty Cycle

750 to 4,000 pages

Maximum Monthly Duty Cycle

100,000 pages

Interface

High-speed USB 2.0;

IEEE 802.3 10/100/1000Base-Tx ；

USB interface: rear USB DEV (1)

Input voltage

110V： AC110-127V, 50/60Hz, 12A

220V： AC220-240V, 50/60Hz，6.5A

Power consumption

print average：≤650W ；

ready：≤8W；

sleep：≤1.4W

shutdown ≤0.5W

Energy Star standards

Energy Star 3.2

Noise

Print：≤56dB(A)

Ready：≤30dB(A)

Mute：≤50dB(A)

Operating Environment

Recommended temperature:10～32℃；

basic used temperature：5～35℃；

Humidity range：20% ～ 80%

Altitude：≤3000m

Print Speed

42ppm (A4 single-sided)

44ppm (Letter single-sided)

70ppm (A5 long edge single-sided)

A5 short edge: 9ppm

Duplex print speed

20spm（A4）

First print out time

≤5.9s

Print Languages

PCL5e、PCL6、PS、GDI

Duplex printing

Auto

U-disk print

No

Mobile print

AirPrint，Mopria™ Print Service，Mopria Scan、APP print(iOS App/Android App)

NFC

NO

Operating system compatibility

Microsoft Windows：

Server2008/Server2012/Server2016/2019/2022/XP/Win7/Win8/Win8.1/Win10/win11（32/64 bit）

Mac OS：10.10~14.3

Linux Ubuntu 16.04/18.04/20.04/22.04/24.04/

Debian 10.0/Centos 7（32/64 bit,intel Processor）；

Astra Linux Special Edition V1.6/Redhat 8.2.0/ Centos 8.2(64 bit,intel Processor)

Android：8.0 and later

iOSAPP：iOS 13 and later

HarmonyAPP：support HarmonyOS 2-4、HarmonyOS NEXT

Other printing functions

Booklet printing, mute printing, envelope printing without wrinkles,confidential printing, PDF printing

Paper input tray

standard input tray：250 pages;

Multipurpose input tray：60 pages;

Optional tray：550 pages (Maximum:2);

Max input tray：1,410 pages

Paper output tray

150 pages

Paper output full detection

YES

Accessory

PT-511H (Optional tray 550 Pages -Maximum:2)

Media type

1. Automatic paper feeder: plain paper, thick paper, transparent film, thin paper, recycled paper

2. Multi-purpose paper feeder: plain paper, thick paper, card paper, label paper, envelope, thin paper, extra thick paper

3. Optional paper tray: plain paper, thick paper, thin paper

Media size

A4, A5, JIS B5, IS0 B5, A6, Letter, Legal, Executive, Folio, Oficio,

Statement, Japanese Postcard, Monarch Env, DL Env, C5 Env, C6 Env, No.10 Env, ZL, Big 16K, Big 32K, 16K, 32K, B6, Yougata4, Postcard, Younaga3, Nagagata3, Yougata2

Minimum support ed size: 80mm x 148mm

Maximum support ed size: 216mm x 356mm

Media weight

input tray：60-120g/㎡

Multipurpose tray：60-200g/㎡

Optional tray：60-120g/㎡

Consumable Type

Toner Cartridge & Drum Unit

Starter Cartridge

TL-*5220 (3,000 pages）

Starter drum unit

DL-*5220 （30,000 pages）

Standard Cartridge

TL-*5220（3,000 pages）

TL-*5220H （6,000 pages）

TL-*5220X （15,000 pages)

Standard drum unit

DL-*5220（30,000 pages）

Printer Dimensions(D*W*H)

366*350*260mm

Package Dimensions(D*W*H)

452*428*333 mm

Printer net weight（kg)

9.3kg (With consumable )

Printer gross weight (kg)

11.2kg
