TVS MSP 270 classic plus 9W | 80 column Dot Matrix Printer
Original price was: ₹18,495.00.₹15,000.00Current price is: ₹15,000.00.
Discover unmatched reliability with the MSP 270 Classic Plus printer, boasting 15,000 power-on hours and up to 200 million characters for the print head. Equipped with maintenance-free silicon self-lubrication and an iSense built-in self-diagnostic tool, it offers various connectivity options and guarantees consistent, high-quality performance across diverse environments.
15000 power-on hours – higher reliability
200 million characters for print head, 40 million characters with 3 additional ink heads
Silicon self lubrication – maintenance free
iSense built-in self diagnostic tool
Print head draft: 10/12/15 CPI – 270/320/375
Parallel/ USB/ Serial (Optional)
Wide operating voltage: 90V to 270V AC
Brand : TVS
Warranty : 1 Year or As Per TVS Service Center
Technical Details
Print Method
Serial Impact Dot Matrix
Number of Pins in Head
9 pins
Print Direction
Bi-directional
Control Code
ESC / P, IBM Proprinter
Print Width
80 Column
Print Head Life
200 Plus Million Characters
Print Speed
High Speed Draft
10 / 12 / 15 cpi 350/ 360 / 400 cps
Draft
10 /12 /15 cpi 270 / 320 / 375 cps
NLQ
10 / 12 / 15 65 /75 /75 cps
Print Characteristics
Character Sets
Resident Printer font
Draft
Draft
Near Letter Quality
Roman, Sans Serif, Script
Resident Barcode Fonts
Code 3 of 9
Printable Columns
Pitch
10/ 12/ 15/ 17/ 20 cpi 80/ 96/ 120/ 137/ 160 cpl
Paper Handling
Paper Path Tractor / Manual
Top, rear and bottom
Continuous Tractor
Convertible push and pull
Cut Sheet (Single Sheet)
3.5 -10″
Cut Sheet Width
3.5 -10″
Paper Thickness
0.3 mm
Continuous Paper
3.5 -10″
Paper Feeding
Standard
Friction, Push Tractor
Copies
1+3 with carbon
Line Spacing
“4.23mm (1/6″”) or programmable in increments of 0.118mm (1/216″”)”
Input Data Buffer
100 KB
Interface
Bi-directional parallel (I pEE-1284 ) nibble mode suported USB 2.0 Full-Speed Serial (Optional)
Ribbon Cartridge
Standard
Patented TVS-E ribbon cassette with user replaceable Ink bank
Ribbon Life
40 Million characters with 3 additional inkbanks
Reliability
Mean Time Between Failure (MTBF)
15000 POH
Acoustics
55 dB (A) in ISO 7779 Sonic Pattern
Emulation
EPSON ESC/P, IBM Proprinter
Control Panel
4 switches and 5 LEDs
Environmental Conditions (Operating)
Temperature
(+5 C to +45C)
Humidity
10% to 80%
Electrical Specification
Rated Voltage
90V – 270V AC
Rated Frequency
47 -63 Hz
Power Consumption
Operating
34W – Self test
Standard by
12 W
Printer Driver / Utility
Operating System
“Windows 9X, NT 4.0, ME, 2000, 2003, XP, VISTA, Windows 7, Linux”
Electronic Guide
HTML Based
Dimesions Size ( W D H) mm
433 X 379 X 147 mm
Weight
5.7 kg
Warranty
1 year
Suitable for
Retail | Pharmacy | Hospitality
