TVS MSP 270 star bluetooth 9W | 80 column Dot Matrix Printer

Print Method

Serial Impact Dot Matrix

Number of Pins in Head

9 pins

Print Direction

Bi-directional

Control Code

ESC / P, IBM ProPrinter

Print Width

80 Column

Print Head Life

200 Plus Million Characters

Printer Speed

320 CPS

Print Speed

High Speed Draft

10 / 12 / 15 cpi | 350/ 360 / 400 cps

Draft

10 /12 /15 cpi 270 / 320 / 375 cps

NLQ

10 / 12 / 15 65 /75 /75 cps

Print Characteristics

Character Sets Resident Printer font

Draft

Draft

Near Letter Quality

Roman, Sans Serif, Script

Resident Barcode Fonts

Code 3 of 9

Printable Columns

Pitch

10/ 12/ 15/ 17/ 20 cpi | 80/ 96/120 / 137/ 160 cpl

Paper Handling

Paper Path Tractor / Manual

Top, rear and bottom

Continuous Tractor

Convertible push and pull

Cut Sheet (Single Sheet)

3.5 -10″

Cut Sheet Width

3.5 -10″

Paper Thickness

0.3 mm

Continuous Paper

3.5 -10″

Roll Paper

Paper Feeding

Standard

Friction, Push Tractor

Copies

1+3 with carbon

Line Spacing

4.23mm (1/6″) or programmable in increments of 0.118mm (1/216”)

Input Data Buffer

100 KB

Interface

Interface

Bluetooth 5.0, Bi-directional parallel, (IEEE-1284 nibble mode supported), USB 2.0 Full-Speed Serial (Optional)

Ribbon Cartridge

Standard: Patented TVS-E ribbon cassette with user replaceable Ink bank

Reliability

Mean Time Between Failure (MTBF): 15000 POH

Acoustics

55 dB (A) in ISO 7779 Sonic Pattern

Emulation

EPSON ESC/P, IBM Proprinter

Control Panel

4 switches and 5 LEDs

Environmental Conditions (Operating)

Temperature

(+5 C to +45C)

Humidity

10% to 80%

Electrical Specification

Rated Voltage

90V – 270V AC

Rated Frequency

47 -63 Hz

Power Consumption

Operating

34W – Self test

Operating

34W – Self test Standard by: 12 W

Standard by

12 W

Printer Driver / Utility

Operating System

Windows 9X, NT 4.0, ME, 2000, 2003, XP, VISTA, Windows 7, Linux

Electronic Guide

HTML Based

Dimesions Size ( W D H) mm

433 X 379 X 147 mm

Weight

5.7 kg

Warranty

1 year
