TVS BS-i201s WL 2D wireless barcode scanner

Light Source

617nm LED Aimer
White LED

Supported

1D: EAN, UPC, Code 39, Code 93, Code 128, UCC/EAN 128, Codabar, Interleave 2 of 5, ITF-6, ITF-4, ISBN, ISSN, MSI-Plessey, GS1 Databar, GS1 Composite Code, Code 11, Industrial 25, Standard 25, Plessey, Matrix 2 of 5.
2D: QR Code, Data Matrix, PDF417, Aztec, Maxicode, Micor QR, Micor PDF417, Hanxin Code

Resolution

Resolution

Scan mode

Manual /Continuous /Automatic

Induction Scanning

Scan speed: 150 scans per second
Scan angle: Yaw±55°, Rotation 360°, Pitch±55°
Precision: ≥5mil
Contrast: ≥20%
Depth of scan field: EAN13 50-200 mm (13 million); QR 25-240 mm (20 million); PDF417 30-130 mm (6.67 million)

Error rate

1 /5 million

Interface

USB-HID

Communication mode

Pairing dedicated

receiver

2.4G communication | Pairing Mobile

Bluetooth Devices

Bluetooth BLE 4.0

Transmission distance

30 – 50 meters (Open distance)

Storage mode

Offline storage Mode: When the scanner exits the connection range, the data is automatically stored. Storage capacity is 512000 characters.
Inventory storage mode: Scanner can enter inventory mode, storage capacity is 512000 characters.

Pairing Mode

One to One: One Scanning Gun Pairs One Receiver | One scanner paired with a Bluetooth mobile device

Operating temperature

-20℃~50℃

Storage temperature

-40℃~70℃

Relative humadity

5% ~95% RH (Non condensing)

Dimensions

90*66*173 mm

Weight

130g

Cable length

1.2 meters

Drop shock resistence

Withstands multiple times 3 meters drops to concrete

Material

ABS+PC

Voltage

DC5V±5%

Operating current

when not scanning code ≥26mA

Battery working time

6 hours

Lithium battery

1400mA

Standby current

0mA (Standby is to cut off battery power)

Charging time

3.5 hours

Charge mode

Square USB charging cable
plug straight charge
